1. Used for welding colorful profiles, and can clean welding slag in one time, without showing the bottom color.
2. Co-extrusion tool adopts aluminum alloy material, precisely proceed with high-frequency quenching.
3. Equipped with automatic blowing system, can improve work efficiency.
1. Used for welding colorful profiles, and can clean welding slag in one time, without showing the bottom color.
2. Co-extrusion tool adopts aluminum alloy material, precisely proceed with high-frequency quenching.
3. Equipped with automatic blowing system, can improve work efficiency.
4. PLC control, pneumatic drive, simple operation, stable capability.
5. Weld three-point, two point, single point, transom, cross -transom and special angle.
Model number | SETH-1A |
Power supply | 220V 50Hz |
Air consumption | 50L/min |
Input power | 1.5kw |
Welding profile height | 20~100mm |
Welding profile width | ≤120mm |
Welding mullion width | ≤110mm |
Operation air pressure | 0.6 ~ 0.8Mpa |
Dimension(L*W*H) | 700*900*1700mm |
